MGAprime H2
(Special edition for China: "MGA6plus)
- Precise and very stable offset measuring technique by means of non dispersive infrared (NDIR) technique, for enhanced long time measurements
- Up to 8 gas NDIR measurement: CO/CO2/C3H8/CH4/SO2/NO/NO2/N2O/H2 and oxygen with O2-PM (paramagnetic cell)
- Remote display through MRU4U App via bluetooth on smartphone or tablet or trough VCN server via LAN/WLAN
- Wireless data transfer via Bluetooth dongle or WLAN dongle or via VNC server using LAN/WLAN
- Integrated, efficient dual heat exchanger gas cooler (Peltier type) with dual automatic condensate draining pumps
- Using single beam through sample cell for NDIR measurements
- Automatic zeroing by means of 3-way solenoid valve, internal sample flow volume measurement
- Strong, regulated sample gas pump and easy replaceable, effective PTFE filter
- Internal sample flow monitoring with display and alarm
- Zero gas (ambient air) air inlet nozzle and passive VENT outlet of sample gas (for use inside laboratories)
- O2 referencing (normalisation) to user settable value
- Large fuel type list incl. self choose fuels with user definable parameters
- Complete combustion calculation using country specific fuel type list
- Automatic internal test and control of soft- and hardware functions
- Automatic measurement incl. data logging function
- 7” high-resolution (800x480 pixel) TFT colour display with swipe and touch technique, with LINUX operating system
- Results stored in database - possibility to view entire measurement session in graphical form, create measurement reports, export data to CSV files, and more
- PC communication via LAN - Ethernet
- Data transfer to PC over LAN Ethernet (RJ45 socket) or USB
- Analog outputs (8-channels), analog inputs (4-channels)
- Modern and robust design, Aluminium enclosure with rubber molded impact protection for use in harsh industrial environment
| Glas flow velocity and mass calculation by using a Pitot tube | |
H2S-measurement 0...500, overload up to 2.000 ppm |  |
| Range extension CO (NDIR) to 100.000 ppm | |
Combustion air temperature probe, 300 mm w/ PTFE cone and 2,7m cable |  |
Pitot tube, L-type, with temperature measurement 100 x Ø 3mm |  |
Darcy tubes, Type S for flow velocity measurement, incl. temperature measurement, 300, 1.000 or 1.500mm length |  |
WLAN/USB printer with LiIon battery, 80mm paper width and battery charger |  |
"Pelicase" style transport case suitable for flight transportation |  |
Glass wool filter material 1 carton=50x30g for 750 filtering processes |  |
Particulate filter element for low dust filter cartridge (pack of 10pcs) |  |
Printer paper 80mm width thermo paper, pack of 5 rolls |  |
IP42 soft padded nylon bag for applications in rainy conditions |  |
Adapter non-MRU heated sampling line to connect 6mm steel tube of non-MRU heated sampling line to analysers gas inlet port |  |
Heat deflector shield Ø 150mm for Ø 10mm tubes |  |
Probe tube holder 1/2"-12mm for firm and tight probe tube fixation on the gas pipe |  |
Exchangeable probe tube, Type TR from 300 ... 1.500 mm, stainless or inconel steel |  |
Industrial probe head, HPI, heated with integrated heater, 160°C temperature regulated by analyser |  |
Heated gas sampling line, various lengths for probe HPI, with temperature control and regulation by analyser, quick coupling to probe head |  |
| Measuring range | |
| H2 | 0...1.000ppm, Überlast bis 2.000ppm 0...10.000ppm, overload 20.000ppm |
| O2 | (paramagnetic) 0 ... 25,00 % |
| CO2 | (NDIR) 0 ... 40 % |
| CO | (NDIR) 0...175 / 10.000 ppm |
| HC (CH4) | (NDIR) 0 ... 500 / 10.000 ppm |
| HC (C3H8) | (NDIR) 0 ... 200 / 5.000 ppm |
| NO | (NDIR) 0 ... 200 / 4.000 ppm |
| NO2 | (NDIR) 0 ... 150* / 1.000 ppm *only possible with optional acid dosage box |
| SO2 | (NDIR) 0 ... 150* / 4.000 ppm *only possible with optional acid dosage box |
| N2O | (NDIR) 0 ... 100 / 500 ppm |
| Fluegas temperature | 0°C ... 1.200°C |
| Combustion air temperature | 0°C ... 500°C |
| Ambient air temperature | 0°C ... 100 °C |
| Differential pressure | -120 ... +120 hPa |
| Flow Velocity | 3 ... 100 m/s |
| Dimensions and other data | |
| Operating system | LINUX |
| Display | 7“ TFT (800 x 480 px) colour display, backlit, with touch pad |
| Data storage | internal 10.000 data sets, external USB stick |
| Interfaces | Ethernet, Bluetooth, WLAN, RS485 |
| Printer | external thermal printer only |
| Battery capacity | Li-Ion , 96 W, for approx. 1 hour „stand-by“ |
| Operating temperature | +5 ... +50 °C ; RH up to 95 % non condensing |
| Storage temperature | -20 ... +50 °C |
| Power supply | 86 ... 265 Vac / 47 ... 63 Hz / 105 W (analyser only) |
| Protection | IP20 (or IP42 inside transport case) |
| Dimensions | 430 x 290 x 150 mm (w x H x D) |
| Weight | approx. 7,5 kg for minimal configuration |
